Heavy-Duty 4-Stroke Engine
A genuine replacement Titan Pro 7HP 212cc 4-Stroke Petrol Engine (Model 170F), designed for high durability and performance across a wide array of garden machinery, wood chippers, tillers, and custom equipment builds.
Power your heavy-duty equipment with this dependable 212cc OHV single-cylinder engine. Proven in the UK for over 15 years, the 170F engine delivers reliable 7HP output at a fraction of the cost of legacy brand engines. Built with a 70mm bore and 54mm stroke, a generous 4.3L fuel tank, and robust pull-start recoil, it provides dependable torque for wood chippers, shredders, rear-tine rotavators, pressure washers, and go-karts.
Titan Pro Tech Tip: Output Shaft Selection & Engine Maintenance
Important Shaft Compatibility: This engine is supplied in two distinct straight output shaft sizes. Please verify your existing clutch or pulley bore diameter before purchasing:
• 19mm Shaft: Fits the Titan Pro TP700 Rear Tine Tiller and general machinery.
• 25mm Shaft: Fits the Titan Pro TP600 Chipmunk Wood Chipper.
Prior to initial engine start, fill the crankcase with 0.6L of 10W-30 engine oil. Set spark plug gap to 0.7-0.8mm and torque to 18-22 N.m for optimal starting reliability.
Featuring a heavy-duty cast iron cylinder sleeve, low-oil shutdown protection, and a red and black industrial finish, this 17.05kg engine offers long-term reliability for domestic and commercial machinery.
Key Features:
• Powerful 7HP 212cc 4-stroke single-cylinder OHV engine (Model 170F)
• Two shaft options: 19mm (TP700 Tiller) or 25mm (TP600 Chipmunk Chipper)
• 4.3 Litre fuel capacity and 0.6 Litre engine oil sump
• Proven reliability across UK conditions for over 15 years
• Versatile engine choice for chippers, rotavators, tillers, go-karts, and custom builds
• Cost-effective, heavy-duty alternative to expensive branded replacement engines
• Includes free UK delivery to all postcodes
7HP / 212cc Output
High-torque 4-stroke OHV engine built for demanding machinery, tillers, and chippers.
19mm or 25mm Shaft
Select 19mm for TP700 Tillers or 25mm for TP600 Chipmunk Chippers before placing your order.
Free UK Delivery
This Titan Pro 7HP 212cc Petrol Engine includes free delivery directly to all standard UK postcodes.
Please note: Engines are shipped dry without oil or fuel. Always fill with 0.6L of correct 4-stroke engine oil before initial startup. Box dimensions: 40cm x 38cm x 37cm (Boxed Weight: 17.05kg).
| Technical Specifications |
| Engine Model |
Titan Pro 170F |
| Engine Type |
4-Stroke OHV Single Cylinder |
| Displacement |
212cc |
| Power Output |
7 HP |
| Output Shaft Sizes Available |
19mm (TP700 Tiller) / 25mm (TP600 Chipper) |
| Bore & Stroke |
70mm x 54mm (3.03" x 2.12") |
| Fuel Tank Capacity |
4.3 Litres |
| Lubricant / Oil Capacity |
0.6 Litres |
| Spark Plug Gap |
0.7 - 0.8mm |
| Spark Plug Torque |
18 - 22 N.m |
| Valve Clearance (Intake) |
0.08 - 0.12mm |
| Valve Clearance (Exhaust) |
0.13 - 0.18mm |
| Colour / Finish |
Red / Black |
| Boxed Dimensions |
40cm x 38cm x 37cm |
| Boxed Weight |
17.05 kg |
| Condition Status |
New |
| Delivery Cost |
Free (All UK Postcodes) |
