Genuine OEM Kohler Complete Engine
Experience premium performance with the genuine Kohler XTX775 Petrol Engine. Designed for demanding domestic and professional applications, the XTX775 delivers outstanding reliability, effortless starting and exceptional durability, making it ideal for walk-behind lawnmowers and a wide range of outdoor power equipment.
As the flagship model in the Kohler XT/XTX Series, the XTX775 features advanced engine technologies that reduce maintenance while providing consistent power, even in tough working conditions. Best of all, the engine is designed to never require an oil change—simply check the oil level before each use and top up when necessary.
Built with cast-iron cylinder liners for enhanced durability, the XTX775 is engineered to deliver years of dependable service.
Titan Pro Tech Tip: Engine Swap & Maintenance Protocol
Replacement engines are shipped completely dry without engine oil for transit safety. Prior to turning over the engine for the first time, fill the crankcase with 0.59L of fresh 4-stroke engine oil (SAE 10W-30 or SAE 30) and confirm the level on the dipstick. While the XTX series eliminates oil changes through advanced filtration and thermal management, regularly check the oil dipstick level before each operation. When mounting the engine to your mower frame, check that the 25mm output shaft keyway aligns cleanly with your blade boss adapter before torquing deck mounting bolts evenly.
Key Features:
• Genuine Kohler XTX775 Petrol Engine
• Designed for walk-behind lawnmowers and compatible outdoor power equipment
• No oil changes required – simply check and top up the oil level when needed
• Smart-Choke™ Technology – easy starting with no priming or manual choke required
• Easy-Pull™ Technology – reduces pull effort for effortless starting
• Accu-Fill® Fuel Tank – larger angled filler neck helps minimise fuel spills
• Consistent-Cut™ Technology – maintains engine speed under demanding conditions
• Heavy-duty cast-iron cylinder liner for maximum durability and engine protection
• Suitable for domestic and professional use
Never-Change Oil Tech
Engineered to operate lifetime-long without oil drains—just check the dipstick level and top up as needed.
Smart-Choke™ Start
Automatic thermal management eliminates manual choke levers and primer bulbs for instant recoil starts.
Free UK Delivery
This genuine standalone Kohler XTX775 173cc engine includes fast, free delivery directly to all standard UK postcodes.
Please note: Replacement engines are shipped dry without oil inside reinforced outer cartons to safeguard engine controls, ignition modules, and vertical output shafts during transit.
| Technical Specifications |
| Engine Model |
Kohler XTX775 Series |
| Engine Type |
Four-Cycle, Single-Cylinder, Air-Cooled, Vertical Shaft, Petrol, OHV with Cast Iron Liner |
| Displacement |
173cc (10.6 cu in) |
| Certified Power Output |
10.11 Nm (7.46 ft-lbs) @ 2800 RPM |
| Output Shaft Diameter |
25mm |
| Bore x Stroke |
70mm x 45mm (2.7 in x 1.8 in) |
| Compression Ratio |
8.5:1 |
| Oil Capacity |
0.59 Litres (0.625 US Quarts) |
| Lubrication System |
Splash Lubrication (Just Check & Add - No Oil Changes) |
| Dry Weight |
12.2 kg (26.9 lbs) |
| Gross Packaged Weight |
13.64 kg |
| Overall Dimensions (L x W x H) |
434mm x 353mm x 279mm (17.1 in x 13.9 in x 11 in) |
| Emissions Compliance |
EU Stage V, EPA Phase III, CARB Phase III, China Phase II |
| Condition Status |
New |
| Delivery Cost |
Free (All UK Postcodes) |
